Product Description:
Character height: 0.36"( 9.2mm)
Outer dimensions: 22.5*14*7.2 mm
Polarity: Common anode
White Epoxy black surface
Super bright amber
585-595nm
50-60mcd
Forward voltage: 1.8-2.2V/led
Forward current:5-10mA/led
Emitting colours: red, blue, green, white, amber, orange and yellow
Absolute Maximum Ratings(Ta=25ºC)
| Parameter | Symbol | Ratings | Unit |
| Forward Current(per dice) | Ipm | 20 | mA |
| Reverse Voltage(per dice) | Vr | 5 | V |
| Power Dissipation(per dice) | Pm | 80 | mW |
| Operating Temperature Range | Topr | -40~+85 | ºC |
| Storage Temperature Range | Tstg | -40~+85 | ºC |
| Solder Temperature(≤3 seconds) | Th | 260 | ºC |
Code:Yellow Green- J
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 1.8 |
| 2.4 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensty | Iv | If=10mA | 30 |
| 40 | mcd |
| Spectrum With Of Half Value | △λ | If=10mA |
| 20 |
| nm |
| Wavelength | Dλ | If=10mA | 569 |
| 574 | nm |
Code:Amber/Yellow -Y
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 1.8 |
| 2.5 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensty | Iv | If=10mA | 60 |
| 80 | mcd |
| Spectrum With Of Half Value | △λ | If=10mA |
| 20 |
| nm |
| Wavelength | Dλ | If=10mA | 585 |
| 595 | nm |
Code:Orange -F
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 1.8 |
| 2.4 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensty | Iv | If=10mA | 60 |
| 80 | mcd |
| Spectrum With Of Half Value | △λ | If=10mA |
| 20 |
| nm |
| Wavelength | Dλ | If=10mA | 600 |
| 605 | nm |
Code:Super Bright Red -R
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 1.8 |
| 2.2 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensty | Iv | If=10mA | 50 |
| 60 | mcd |
| Spectrum With Of Half Value | △λ | If=10mA |
| 20 |
| nm |
| Wavelength | Dλ | If=10mA | 630 |
| 635 | nm |
Code:Ultra Bright Red -UR
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 1.8 |
| 2.2 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensty | Iv | If=10mA | 80 |
| 100 | mcd |
| Spectrum With Of Half Value | △λ | If=10mA |
| 20 |
| nm |
| Wavelength | Dλ | If=10mA | 625 |
| 635 | nm |
Code:Pure Green -G
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 2.6 |
| 3.2 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensty | Iv | If=10mA | 120 |
| 180 | mcd |
| Spectrum With Of Half Value | △λ | If=10mA |
| 20 |
| nm |
| Wavelength | Dλ | If=10mA | 515 |
| 525 | nm |
Code:Ultra Bright Blue -BH
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 2.8 |
| 3.2 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensty | Iv | If=10mA | 120 |
| 140 | mcd |
| Spectrum With Of Half Value | △λ | If=10mA |
| 20 |
| nm |
| Wavelength | Dλ | If=10mA | 460 |
| 465 | nm |
Code:Ultra Bright White -WH
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 2.8 |
| 3.2 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensty | Iv | If=10mA | 120 |
| 140 | mcd |
| LED color Temperature | K | If=10mA | 5500 | 20 | 6800 | K |
| Chromaticity Coordinates | X/Y | If=10mA | 0.29,0.32 |
| 0.30,0.33 | nm |
Product Feature:
Forward voltage (high luminous intensity output)
Low power consumption
Extremely low current
Luminous evenly distributed on each segment
Industrial standard size
Provides excellent reliability in bright ambient light
Stable performance
Long lifetime
Meet RoHS/REACH compliant
Applications:
Audio equipments or instrument panels
Home electronic appliances
Numeric displays
Multimedia products
General use for digital indicators,temperature indiators, humidity indicators,process indicators,and so on
Products Applications
7 Segment LED Display, Customized LED Display, Numeric LED Display, Dot matrix LED Display, widely used for home appliances,tempearture indicators, humidity indicators, refrigerator controller,thernostats indicator,heating and cooling control and so on
